Can easily connect the pipes PEX Compression Fitting

Short Description:

Quick and easy pipe fittings are an important component in the pipe fitting system and are characterized by fast and easy installation. Kuaiyi pipe fittings use thermal memory ring technology. Due to the thermal memory characteristics of the pipe itself, it will be closely integrated with the pipe fittings and lock the pipe fittings firmly to achieve a fast and firm connection. This connection method can be completed in seconds, and has good sealing performance and is not prone to leakage.

Product Detail

Product Tags

Advantage

1. Quick and easy connection:
- Easy to operate: No complex tools or professional techniques are required, and it can generally be operated with simple training. For example, you only need to put the Quick-Easy ring on the pipe, use a flaring tool to expand the pipe, and then insert the pipe fitting to complete the connection, which greatly saves construction time and labor costs.
- Efficient installation: The entire connection process takes a short time. Compared with traditional welding, threaded connection, etc., it can complete the connection of a pipe fitting in seconds or minutes, improving the efficiency of construction.

2. The connection is reliable and firm:
- Powerful locking force: Kuaiyi pipe fittings usually use the thermal memory performance of the pipe and the special structural design to generate strong contraction force to lock the pipe fittings. For example, the memory rings of some Kuaiyi pipe fittings will generate strong contraction force after expansion, tightly connecting the pipe fittings and pipes together, and the strength of the connection part can even be comparable to that of the pipe itself.
- Good sealing: The pipe fittings and pipes are tightly connected and have good sealing performance, which can effectively prevent water leakage, water seepage and other problems. After rigorous testing, it can maintain a good sealing state even under high pressure, ensuring the safe operation of the pipeline system.

3. Strong adaptability:
- Good pipe adaptability: It can be used to connect pipes of different materials and specifications. It can also be well adapted to pipes of the same specifications but different wall thicknesses, which increases the use range and flexibility of pipe fittings and reduces the cost of pipe fittings. The trouble of preparing a variety of different pipe fittings due to differences in pipe specifications.
- Good system adaptability: It can match various pipeline systems, whether it is HVAC systems, building water supply and drainage systems, or industrial pipeline systems, etc., it can play a good connection role.

4. Easy maintenance:
- Easy to disassemble: If the pipeline system needs to be repaired, replaced or modified in the future, the disassembly of Kuaiyi pipe fittings is relatively easy and does not require cutting, welding and other complex operations, reducing the difficulty and cost of maintenance.
- Reusable: Under certain conditions, some quick and easy pipe fittings can be reused multiple times, reducing material waste.

5. Safety and environmental protection:
- Material safety: The materials used usually have good chemical stability and corrosion resistance, and will not cause pollution to the transported medium, ensuring the quality and safety of the medium. For example, Kuaiyi pipe fittings made of PPSU are non-toxic and odorless and can be used in drinking water systems.
- Construction safety: No open flame is required during the connection process, which avoids potential safety hazards such as fire. It has important application value especially in some places with high fire protection requirements.

6. Small space occupation: Kuaiyi pipe fittings have a compact structure and reasonable design. They do not need to occupy too much space during the installation process. They are very suitable for places with limited space, such as pipe wells inside buildings, narrow equipment rooms, etc. Big advantage.

7. Cost advantage:
- Low initial investment cost: Compared with some complex pipeline connection technologies and equipment, the price of Kuaiyi pipe fittings is relatively low, reducing the initial construction cost of the pipeline system.
- Low maintenance costs in the later period: Due to its good reliability and easy maintenance, it reduces the maintenance costs and downtime losses caused by pipeline failures in the later period.

CWQ

Product Introduction

Quick and easy pipe fittings are an important component in the pipe fitting system and are characterized by fast and easy installation. Kuaiyi pipe fittings use thermal memory ring technology. Due to the thermal memory characteristics of the pipe itself, it will be closely integrated with the pipe fittings and lock the pipe fittings firmly to achieve a fast and firm connection. This connection method can be completed in seconds, and has good sealing performance and is not prone to leakage.

PPSU (polyphenylsulfone) is a commonly used material for Kuaiyi pipe fittings. It has good stability, heat resistance and chemical resistance. It is often used in hot and cold drinking water systems. The biggest advantage of this material is that it is resistant to high temperatures and can be used for more than 14 years in a steam environment of 145 degrees. It is lead-free, non-toxic, and has excellent environmental performance. It is often used in high-end baby bottles.

Overall, PPSU (polyphenylsulfone) quick and easy fittings are not only resistant to strong impacts and chemicals without causing damage, but these fittings are odorless and tasteless, making them suitable for drinking water use. With its fast, easy, reliable connection method and good performance, Kuaiyi pipe fittings have been widely used in many fields, such as: petroleum, chemical industry, electric power, papermaking, food processing and other industries, providing better installation and use of pipeline systems. Convenience is provided.

The main advantages of these PPSU fittings compared to brass fittings are:
1. Less weight, making them lighter.
2. Best thermal and sound insulation materials
3. Better resistant to exposure to chemicals.
4. They will not oxidize or corrode, and are waterproof.
5. Due to its low internal roughness, the load loss is smaller.
6. It does not add metal oxides to the water.
7. Strong impact resistance and high pressure resistance because they can increase in length before breaking.
